Zetron PTM600 6-in-1 Flue Gas Analyzer
$3,295.00$3,999.00
PTM600 flue gas analyzer has the function of measuring the gas concentration for O2/CO/CO2/H2S/CH4/H2 at the same time, suitable for chemical plant, power plant, landfill, incineration station, port, sewage treatment plant, storage facilities, underground facilities, and more.
The product is provided with high measurement precision, stable performance and simple operation and convenient to carry.
It is possible to simultaneously detect 1 ~ 6 types of gases, which can be expanded to 18 or more types of gases, and the types for detection are more than 500 types.
Description
|
Gases to be detected
|
O2/CO/CO2/H2S/CH4/H2
|
||||
|
Detection range
|
O2:0-30%VOL
CO: 0-1000ppm
CO2: 0-100%VOL
H2S: 0-200ppm
CH4:0-100%LEL
H2: 0-1000ppm
other ranges can be customized
|
||||
|
Resolution
|
0.1ppm
|
||||
|
Detection principle
|
O2: UK Alpha Electrochemical sensor
CO2: Infrared sensor H2S: Electrochemical sensor CH4: Catalytic combustion sensor f H2: Electrochemical sensor |
||||
|
Allowable error
|
≤±2% F.S (other or higher precision levels can be customized)
|
||||
|
Linearity
|
≤±2%
|
Repeatability
|
≤±2%
|
Uncertainty
|
≤±2%
|
|
Response time
|
T90≤20 seconds
|
Recovery time
|
≤30 seconds
|
||
|
Working environment
|
Temperature: -40 ℃ ~ + 70 ℃, humidity: ≤10 ~ 95% RH, and built-in filters can be used in high humidity or high dust environment.
|
||||
|
Sample gas temperature
|
-40 ℃ ~ + 70 ℃, and the optional configuration of high-temperature sampling and cooling filter handle will be possible to detect
the smoke gas at the temperature of 1300 ℃. |
||||
|
Power supply
|
3.6VDC, 10000mA high capacity rechargeable polymer battery
|
||||
|
Display mode
|
3.5-inch high-definition color screen
|
||||
|
Detection mode
|
Built-in pump-suction type measurementFlow rate at 800 ml / min
|
||||
|
Alarm mode
|
It is possible to set as sound & light alarm, vibration alarm, turning off the alarm.
|
||||
|
Protection level
|
IP66
|
||||
|
Explosion-proof type
|
Intrinsically safe type
|
||||
|
Explosion-proof mark
|
Exia II CT6
|
||||
|
Exterior dimensions
|
230×210×120 mm (L×H×W)
|
||||
|
Weight
|
2.5Kg
|
||||
